Terminal Connector
ACN32-A Type Terminal Connector
● Rated voltage:400V
● Rated current:32A
● Voltage resistance:4KV
● Operating Temperature:-30°C~+105°C
| Item No. | Body material | Wire range | Connecting wire numbers | Wire strip length (mm/in) | ||
| Flexible wire | Non-flexible wire | In | Out | |||
| ACN32-A01 | PA | 0.08~4.0mm² (28-12AWG) | 0.08~2.5mm² (28-14AWG) | 1 | 1 | 10 / 0.39" |
| ACN32-A01D* | 1 | 1 | ||||
| ACN32-A02 | 2 | 2 | ||||
| ACN32-A03 | 3 | 3 | ||||
| ACN32-A04 | 4 | 4 | ||||
| ACN32-A05 | 5 | 5 | ||||
| ACN32-A01C | PC | 0.08~4.0mm² (28-12AWG) | 0.08~2.5mm² (28-14AWG) | 1 | 1 | 10 / 0.39" |
| ACN32-A01CD* | 1 | 1 | ||||
| ACN32-A02C | 2 | 2 | ||||
| ACN32-A03C | 3 | 3 | ||||
| ACN32-A04C | 4 | 4 | ||||
| ACN32-A05C | 5 | 5 | ||||
*Note: 1.D means DIN Rail type; C means PC body, transparent color 2.lever color can be customized
